[SPARK-30768][SQL] Constraints inferred from inequality attributes #27518

wangyum · 2020-02-10T06:12:36Z

What changes were proposed in this pull request?

In our production environment, there are many queries similar to this pattern:

CREATE TABLE spark_30768_1(user_id DECIMAL(18,0), src_cre_dt DATE /*other columns*/);
CREATE TABLE spark_30768_2(user_id DECIMAL(18,0), start_dt DATE, end_dt DATE /*other columns*/);

SELECT spark_30768_1.src_cre_dt /*other columns*/
FROM
  spark_30768_1
  INNER JOIN spark_30768_2 ON spark_30768_1.user_id = spark_30768_2.user_id
  AND spark_30768_1.src_cre_dt >= spark_30768_2.start_dt
  AND spark_30768_1.src_cre_dt < spark_30768_2.end_dt
WHERE spark_30768_1.src_cre_dt BETWEEN date '2020-02-01' AND date '2020-02-07'

In this case, we can infer more constraints to improve query performance. E.g. spark_30768_2.start_dt <= '2020-02-07' inferred from spark_30768_2.start_dt <= spark_30768_1.src_cre_dt <= '2020-02-07' and spark_30768_2.end_dt > '2020-02-01' inferred from spark_30768_2.end_dt > spark_30768_1.src_cre_dt >= '2020-02-01'. This PR add support infer these constraints from inequality attributes.

Why are the changes needed?

Improve query performance. Teradata support this optimization:
https://docs.teradata.com/reader/Ws7YT1jvRK2vEr1LpVURug/V~FCwD9BL7gY4ac3WwHInw?section=xcg1472241575102__application_of_transitive_closure_section

Does this PR introduce any user-facing change?

No.

How was this patch tested?

Unit test and benchmark test.

Benchmark code and benchmark result:

import org.apache.spark.benchmark.Benchmark
import org.apache.spark.sql.SaveMode.Overwrite

val numRows = 1024 * 1024
spark.range(numRows).selectExpr("id as c1", "id as c2").write.saveAsTable("t1")
spark.range(numRows).selectExpr("id as c1", "id as c2").write.saveAsTable("t2")

val title = "Constraints inferred from inequality constraint"
val benchmark = new Benchmark(title, numRows, minNumIters = 5)
benchmark.addCase(s"t1.c1 > ${numRows - 1000}") { _ =>
  spark.sql(s"select count(*) from t1 join t2 on (t1.c1 > t2.c1 and t2.c1 > ${numRows - 1000})").write.format("noop").mode(Overwrite).save()
}

benchmark.addCase("t1.c1 < 1000") { _ =>
  spark.sql("select count(*) from t1 join t2 on (t1.c1 < t2.c1 and t2.c1 < 1000)").write.format("noop").mode(Overwrite).save()
}
benchmark.run()

Before this PR:

Java HotSpot(TM) 64-Bit Server VM 1.8.0_191-b12 on Mac OS X 10.13.6
Intel(R) Core(TM) i7-7820HQ CPU @ 2.90GHz
Constraints inferred from inequality constraint:  Best Time(ms)   Avg Time(ms)   Stdev(ms)    Rate(M/s)   Per Row(ns)   Relative
------------------------------------------------------------------------------------------------------------------------
t1.c1 > 1047576                                   30519          31171         567          0.0       29105.2       1.0X
t1.c1 < 1000                                      50525          50906         331          0.0       48184.7       0.6X

After this PR:

Java HotSpot(TM) 64-Bit Server VM 1.8.0_191-b12 on Mac OS X 10.13.6
Intel(R) Core(TM) i7-7820HQ CPU @ 2.90GHz
Constraints inferred from inequality constraint:  Best Time(ms)   Avg Time(ms)   Stdev(ms)    Rate(M/s)   Per Row(ns)   Relative
------------------------------------------------------------------------------------------------------------------------
t1.c1 > 1047576                                     179            191          15          5.9         170.5       1.0X
t1.c1 < 1000                                        175            195          27          6.0         166.7       1.0X

Also test this feature in our production environment, it can significantly improve the query performance of at least 6 SQLs (a total of 200 SQLs):

SQL ID	Before this PR(seconds)	After this PR(seconds)
323	108	73
368	56	26
372	72	28
373	60	26
374	113	44
375	82	55

For e.g. SQL 372. It prevents (18,413,424,580 - 162,205,133 = 18,251,219,447) rows from participating in shuffle:
Before this PR:

After this PR:

SparkQA · 2020-02-10T08:05:02Z

Test build #118120 has finished for PR 27518 at commit b59a810.

This patch fails due to an unknown error code, -9.
This patch merges cleanly.
This patch adds no public classes.

wangyum · 2020-02-10T08:05:31Z

retest this please

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala

SparkQA · 2020-02-10T12:31:10Z

Test build #118131 has finished for PR 27518 at commit b59a810.

This patch fails PySpark unit tests.
This patch merges cleanly.
This patch adds no public classes.

wangyum · 2020-02-10T12:46:20Z

retest this please

SparkQA · 2020-02-10T17:42:01Z

Test build #118163 has finished for PR 27518 at commit b59a810.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

peter-toth · 2020-02-11T20:37:18Z

Is the title correct? Isn't what you do here is constant propagation among constraints?
Obviously it helps with inequalities of attributes, but also helps where you have complex equalities like select t1.* from SPARK_30768_1 t1 join SPARK_30768_2 t2 on f(t1.c1) = t2.c1 where t1.c1 = 3 (where f is a deterministic function).

BTW, I have a PR open to enhance ConstantPropagation: #24553 where among other enhancements I try to extend propagation of attribute => constant mapping to propagation of deterministic expression => constant mapping. Maybe you could do expression => constant propagation here as well.

wangyum · 2020-02-12T12:47:07Z

@peter-toth I'd like to handle another case in this PR:

spark.sql("CREATE TABLE `dw_user_state_history` (`id` DECIMAL(18,0), `change_time` date, `to_state` DECIMAL(9,0)) USING parquet")

spark.sql("CREATE TABLE `dw_user_cntry_hist` (`user_id` DECIMAL(18,0), `start_dt` DATE, `end_dt` DATE) USING parquet")

spark.sql(
  """
    |SELECT
    |	 count(*)
    |FROM
    |	 dw_user_state_history ush
    |	 INNER JOIN dw_user_cntry_hist uch ON (uch.user_id = ush.id AND CAST(ush.change_time AS date) >= uch.start_dt AND CAST(ush.change_time AS date) < uch.end_dt)
    |WHERE
    |	 change_time between '2019-07-01 00:00:00' AND '2019-07-02 00:00:00'
    |""".stripMargin).explain()

The exepected physical plan:

== Physical Plan ==
*(3) HashAggregate(keys=[], functions=[count(1)])
+- Exchange SinglePartition, true, [id=#139]
   +- *(2) HashAggregate(keys=[], functions=[partial_count(1)])
      +- *(2) Project
         +- *(2) BroadcastHashJoin [id#219], [user_id#222], Inner, BuildRight, ((change_time#220 >= start_dt#223) AND (change_time#220 < end_dt#224))
            :- *(2) Project [id#219, change_time#220]
            :  +- *(2) Filter (((isnotnull(change_time#220) AND (change_time#220 >= 18078)) AND (change_time#220 <= 18079)) AND isnotnull(id#219))
            :     +- *(2) ColumnarToRow
            :        +- FileScan parquet default.dw_user_state_history[id#219,change_time#220] Batched: true, DataFilters: [isnotnull(change_time#220), (change_time#220 >= 18078), (change_time#220 <= 18079), isnotnull(id..., Format: Parquet, Location: InMemoryFileIndex[file:/Users/yumwang/opensource/spark/sql/core/spark-warehouse/org.apache.spark...., PartitionFilters: [], PushedFilters: [IsNotNull(change_time), GreaterThanOrEqual(change_time,2019-07-01), LessThanOrEqual(change_time,..., ReadSchema: struct<id:decimal(18,0),change_time:date>
            +- BroadcastExchange HashedRelationBroadcastMode(List(input[0, decimal(18,0), true])), [id=#133]
               +- *(1) Project [user_id#222, start_dt#223, end_dt#224]
                  +- *(1) Filter (((((isnotnull(end_dt#224) AND (start_dt#223 <= 18079)) AND isnotnull(user_id#222)) AND (start_dt#223 < end_dt#224)) AND isnotnull(start_dt#223)) AND (end_dt#224 > 18078))
                     +- *(1) ColumnarToRow
                        +- FileScan parquet default.dw_user_cntry_hist[user_id#222,start_dt#223,end_dt#224] Batched: true, DataFilters: [isnotnull(end_dt#224), (start_dt#223 <= 18079), isnotnull(user_id#222), (start_dt#223 < end_dt#2..., Format: Parquet, Location: InMemoryFileIndex[file:/Users/yumwang/opensource/spark/sql/core/spark-warehouse/org.apache.spark...., PartitionFilters: [], PushedFilters: [IsNotNull(end_dt), LessThanOrEqual(start_dt,2019-07-02), IsNotNull(user_id), IsNotNull(start_dt)..., ReadSchema: struct<user_id:decimal(18,0),start_dt:date,end_dt:date>

peter-toth · 2020-02-12T15:10:19Z

@wangyum, I'm a but confused now. As far as I see based on your changes, in this PR you substitute attribute = constant form of constraints into other constraints to infer new constraints.
So this PR will help with your example query as from select t1.* from SPARK_30768_1 t1 join SPARK_30768_2 t2 on (t1.c1 > t2.c1) where t1.c1 = 3 the new constraint 3 > t2.c1 is inferred.
It will also help with those cases I mentioned:
select t1.* from SPARK_30768_1 t1 join SPARK_30768_2 t2 on abs(t1.c1) = t2.c1 where t1.c1 = 3 as abs(3) = t2.c1 will be inferred.
It will also help here: #27252 (comment) as after both this PR and #27252 are merged, it will solve the issue in the comment of @cloud-fan:

If we have cast(a, dt) = b and a = 1, seems we can also infer cast(1, dt) = b

But, I don't see how it will help with the example query here: #27518 (comment)

wangyum · 2020-02-12T15:54:38Z

@peter-toth 999126c helps the example query.

SparkQA · 2020-02-12T17:35:55Z

Test build #118309 has finished for PR 27518 at commit 999126c.

This patch fails Spark unit tests.
This patch merges cleanly.
This patch adds no public classes.

peter-toth · 2020-02-13T10:33:18Z

@peter-toth 999126c helps the example query.

Thanks @wangyum. I see now that you basically reverted your first commit.
If you don't mind I would open a PR that does some kind of constant propagation among constraints. Probably a bit similar to the first commit in this PR.

wangyum · 2020-02-13T10:50:31Z

@peter-toth Please go ahead. I reverted the first commit because this test will fail:

test("Constraints shouldn't be inferred from cast equality constraint(filter lower data type)") {
  val testRelation1 = LocalRelation('a.int)
  val testRelation2 = LocalRelation('b.long)
  val originalLeft = testRelation1.where('a === 1).subquery('left)
  val originalRight = testRelation2.subquery('right)

  val left = testRelation1.where(IsNotNull('a) && 'a === 1).subquery('left)
  val right = testRelation2.where(IsNotNull('b)).subquery('right)

  Seq(Some("left.a".attr.cast(LongType) === "right.b".attr),
    Some("right.b".attr === "left.a".attr.cast(LongType))).foreach { condition =>
    testConstraintsAfterJoin(originalLeft, originalRight, left, right, Inner, condition)
  }
}

== FAIL: Plans do not match ===
 'Join Inner, (b#0L = cast(a#0 as bigint))                                                  'Join Inner, (b#0L = cast(a#0 as bigint))
!:- Filter (((1 = a#0) AND isnotnull(a#0)) AND (cast(a#0 as bigint) = cast(1 as bigint)))   :- Filter ((1 = a#0) AND isnotnull(a#0))
 :  +- LocalRelation <empty>, [a#0]                                                         :  +- LocalRelation <empty>, [a#0]
!+- Filter (isnotnull(b#0L) AND (b#0L = cast(1 as bigint)))                                 +- Filter isnotnull(b#0L)
    +- LocalRelation <empty>, [b#0L]                                                           +- LocalRelation <empty>, [b#0L]

# Conflicts: # sql/catalyst/src/test/scala/org/apache/spark/sql/catalyst/optimizer/InferFiltersFromConstraintsSuite.scala

SparkQA · 2020-02-14T19:08:52Z

Test build #118434 has finished for PR 27518 at commit d4eb2d7.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-02-16T15:50:47Z

Test build #118505 has finished for PR 27518 at commit df679e6.

This patch fails Spark unit tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-02-17T08:05:02Z

Test build #118526 has finished for PR 27518 at commit 3c9968a.

This patch fails due to an unknown error code, -9.
This patch merges cleanly.
This patch adds the following public classes (experimental):
case class WorkerDecommission(
case class DecommissionExecutor(executorId: String) extends CoarseGrainedClusterMessage

wangyum · 2020-02-17T10:42:00Z

Metrics of Analyzer/Optimizer Rules for TPCDSQuerySuite
Before this PR:

02:32:26.475 WARN org.apache.spark.sql.TPCDSQuerySuite:
=== Metrics of Analyzer/Optimizer Rules ===
Total number of runs: 224786
Total time: 45.803692546 seconds

Rule                                                                                               Effective Time / Total Time                     Effective Runs / Total Runs

org.apache.spark.sql.catalyst.optimizer.Optimizer$OptimizeSubqueries                               6898974687 / 8840587642                         47 / 772
org.apache.spark.sql.catalyst.optimizer.ColumnPruning                                              671684614 / 2740648387                          327 / 2364
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveSubquery                                    1637851386 / 1780942834                         51 / 2159
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveAggregateFunctions                          624455301 / 1744459696                          49 / 2159
org.apache.spark.sql.catalyst.analysis.DecimalPrecision                                            1136163267 / 1355664883                         361 / 2159
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveReferences                                  958843179 / 1132184862                          813 / 2159
org.apache.spark.sql.catalyst.optimizer.PruneFilters                                               21041535 / 875480663                            5 / 1978
org.apache.spark.sql.catalyst.optimizer.BooleanSimplification                                      7949392 / 757989983                             4 / 1592
org.apache.spark.sql.catalyst.analysis.TypeCoercion$ImplicitTypeCasts                              301831588 / 657645402                           78 / 2159
org.apache.spark.sql.catalyst.optimizer.PushDownPredicates                                         374351767 / 641828516                           758 / 1979
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveMissingReferences                           14541719 / 632536654                            10 / 2159
org.apache.spark.sql.catalyst.optimizer.NullPropagation                                            39937489 / 587603524                            42 / 1592
org.apache.spark.sql.catalyst.optimizer.ReorderJoin                                                244728546 / 572349474                           177 / 1592
org.apache.spark.sql.catalyst.optimizer.ConstantFolding                                            158687531 / 564225840                           194 / 1592
org.apache.spark.sql.catalyst.optimizer.ReorderAssociativeOperator                                 0 / 547165121                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyConditionals                                       0 / 532921745                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyBinaryComparison                                   0 / 527530671                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.RemoveNoopOperators                                        48706059 / 526075410                            116 / 2364
org.apache.spark.sql.catalyst.optimizer.SimplifyExtractValueOps                                    0 / 511807420                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyCasts                                              45722796 / 510124455                            83 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyCaseConversionExpressions                          0 / 493219669                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.OptimizeIn                                                 12300150 / 491448204                            27 / 1592
org.apache.spark.sql.catalyst.analysis.UpdateAttributeNullability                                  20208595 / 484413473                            12 / 674
org.apache.spark.sql.catalyst.optimizer.RemoveDispensableExpressions                               0 / 480755936                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.LikeSimplification                                         799298 / 463609379                              1 / 1592
org.apache.spark.sql.catalyst.optimizer.CollapseProject                                            92682031 / 457556748                            215 / 1978
org.apache.spark.sql.catalyst.optimizer.ReplaceNullWithFalseInPredicate                            0 / 456658852                                   0 / 1592
org.apache.spark.sql.catalyst.analysis.TypeCoercion$FunctionArgumentConversion                     227217097 / 442233854                           56 / 2159
org.apache.spark.sql.catalyst.optimizer.InferFiltersFromConstraints                                406969136 / 435459925                           278 / 386

After this PR:

02:28:49.937 WARN org.apache.spark.sql.TPCDSQuerySuite:
=== Metrics of Analyzer/Optimizer Rules ===
Total number of runs: 224786
Total time: 47.011460872 seconds

Rule                                                                                               Effective Time / Total Time                     Effective Runs / Total Runs

org.apache.spark.sql.catalyst.optimizer.Optimizer$OptimizeSubqueries                               7073196527 / 8950854926                         47 / 772
org.apache.spark.sql.catalyst.optimizer.ColumnPruning                                              724531405 / 2931435267                          327 / 2364
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveSubquery                                    1789988207 / 1942196179                         51 / 2159
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveAggregateFunctions                          717122415 / 1838219499                          49 / 2159
org.apache.spark.sql.catalyst.analysis.DecimalPrecision                                            1276704718 / 1524939842                         361 / 2159
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveReferences                                  1003010234 / 1192920997                         813 / 2159
org.apache.spark.sql.catalyst.optimizer.PruneFilters                                               21471500 / 952660373                            5 / 1978
org.apache.spark.sql.catalyst.optimizer.BooleanSimplification                                      9761473 / 773205469                             4 / 1592
org.apache.spark.sql.catalyst.analysis.TypeCoercion$ImplicitTypeCasts                              329430374 / 734067405                           78 / 2159
org.apache.spark.sql.catalyst.analysis.Analyzer$ResolveMissingReferences                           12112700 / 709719203                            10 / 2159
org.apache.spark.sql.catalyst.optimizer.PushDownPredicates                                         399755753 / 663934266                           758 / 1979
org.apache.spark.sql.catalyst.optimizer.ReorderJoin                                                266383835 / 593070778                           177 / 1592
org.apache.spark.sql.catalyst.optimizer.NullPropagation                                            35781183 / 578417823                            42 / 1592
org.apache.spark.sql.catalyst.optimizer.RemoveNoopOperators                                        48387593 / 540807035                            116 / 2364
org.apache.spark.sql.catalyst.optimizer.SimplifyBinaryComparison                                   0 / 535708634                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.ConstantFolding                                            114115625 / 533552246                           194 / 1592
org.apache.spark.sql.catalyst.optimizer.OptimizeIn                                                 12632788 / 529487507                            27 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyCaseConversionExpressions                          0 / 513745956                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.SimplifyConditionals                                       0 / 508586160                                   0 / 1592
org.apache.spark.sql.catalyst.optimizer.InferFiltersFromConstraints                                459543325 / 490828096                           278 / 386

SparkQA · 2020-02-17T15:26:11Z

Test build #118570 has finished for PR 27518 at commit f9a90aa.

This patch fails Spark unit tests.
This patch merges cleanly.
This patch adds no public classes.

HyukjinKwon · 2020-02-25T04:50:37Z

retest this please

SparkQA · 2020-02-25T07:28:52Z

Test build #118895 has finished for PR 27518 at commit f9a90aa.

This patch fails Spark unit tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-02-26T19:26:53Z

Test build #118980 has finished for PR 27518 at commit bfa6039.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-03-07T17:35:17Z

Test build #119516 has finished for PR 27518 at commit 248e3cc.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-03-20T20:27:24Z

Test build #120106 has finished for PR 27518 at commit 248e3cc.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-06-08T18:49:41Z

Test build #123638 has finished for PR 27518 at commit af55a08.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2020-06-12T16:53:31Z

Test build #123919 has finished for PR 27518 at commit 5c76b9d.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

HyukjinKwon · 2020-06-26T11:04:59Z

cc @maryannxue and @cloud-fan FYI

tanelk

Both this and #29650 introduce an while loop to infer constraints from a chain of existing constraints. If either of there gets accepted, the other must be changed to unify these loops.

tanelk · 2020-09-06T14:29:57Z

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala

+      case _: GreaterThanOrEqual => true
+      case _: LessThan => true
+      case _: LessThanOrEqual => true
+      case _: EqualTo => true


EqualTo should not be needed here, as the inferEqualityConstraints should cover all cases including it.

inferEqualityConstraints can not handle all cases, such as constraint with cast.

For example: cast(a as double) > cast(b as double) and cast(b as double) = 1

tanelk · 2020-09-06T14:31:57Z

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala

+    val lessThans = binaryComparisons.map {
+      case EqualTo(l, r) if l.foldable => EqualTo(r, l)
+      case GreaterThan(l, r) => LessThan(r, l)
+      case GreaterThanOrEqual(l, r) => LessThanOrEqual(r, l)
+      case other => other
+    }


Doesn't this duplicate the greaterThans block?
Here you have a < b < c and in the other block you have c > b > a

No. for example:
a > b and 5 > a. we can not infer anything. but we can infer that b < 5 after rewriting a > b and 5 > a as b < a and a < 5.

Is it because of the foldable check? Without it, it should be inferable.

tanelk · 2020-09-06T14:33:43Z

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala

+    var inferredConstraints = Set.empty[Expression]
+    greaterThans.foreach {
+      case op @ BinaryComparison(source: Attribute, destination: Expression)
+        if destination.foldable =>


I think that the foldability is not needed here. The new constraints do not have to only involve constants, but also any attribute.

To avoid generating too many constraints. For example: a > b > c > 1. The expected inferred constraints are: a > 1 and b > 1. a > c is useless.

If a and c are in tihe same side of a join, then it can be pushed down.

How to push down a > c if both a and c are not foldable?

I'm sorry, I used a wrong word. I meant pushed through the join into one of the sides.

tanelk · 2020-09-06T14:41:39Z

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala

+    do {
+      lastInequalityInferred = inferInequalityConstraints(constraints ++ inferred)
+      inferred ++= lastInequalityInferred
+    } while (lastInequalityInferred.nonEmpty)


Could you hit a infinite loop with non deterministic filters? As they are never semantically equal to any other expression (including themselves). I hit that problem in #29650, where I was also working on constraint inference , but from EqualNullSafe.

wangyum · 2020-12-14T02:42:02Z

Thank you all. Merged it to our internal Spark version.

Constraints should be inferred from inequality attributes

b59a810

HyukjinKwon reviewed Feb 10, 2020

View reviewed changes

...talyst/src/main/scala/org/apache/spark/sql/catalyst/plans/logical/QueryPlanConstraints.scala Outdated Show resolved Hide resolved

dongjoon-hyun added the SQL label Feb 10, 2020

peter-toth mentioned this pull request Feb 12, 2020

[SPARK-29231][SQL] Constraints should be inferred from cast equality constraint #27252

Closed

wangyum changed the title ~~[SPARK-30768][SQL] Constraints should be inferred from inequality attributes~~ [WIP][SPARK-30768][SQL] Constraints should be inferred from inequality attributes Feb 12, 2020

Constraints should be inferred from inequality constraints

999126c

wangyum added 2 commits February 14, 2020 21:34

Merge remote-tracking branch 'upstream/master' into SPARK-30768

8843d45

# Conflicts: # sql/catalyst/src/test/scala/org/apache/spark/sql/catalyst/optimizer/InferFiltersFromConstraintsSuite.scala

fix test errors in TPCH

d4eb2d7

Add more tests

df679e6

Merge remote-tracking branch 'upstream/master' into SPARK-30768

3c9968a

Remove semanticEquals Expression

f9a90aa

fix

bfa6039

wangyum changed the title ~~[WIP][SPARK-30768][SQL] Constraints should be inferred from inequality attributes~~ [SPARK-30768][SQL] Constraints inferred from inequality attributes Mar 4, 2020

Add support another real case

248e3cc

Only infer foldable constraints

af55a08

Simplify

5c76b9d

tanelk reviewed Sep 6, 2020

View reviewed changes

wangyum closed this Dec 14, 2020

Uh oh!

[SPARK-30768][SQL] Constraints inferred from inequality attributes #27518

[SPARK-30768][SQL] Constraints inferred from inequality attributes #27518

Uh oh!

Conversation

wangyum commented Feb 10, 2020 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

What changes were proposed in this pull request?

Why are the changes needed?

Does this PR introduce any user-facing change?

How was this patch tested?

Uh oh!

SparkQA commented Feb 10, 2020

Uh oh!

wangyum commented Feb 10, 2020

Uh oh!

Uh oh!

SparkQA commented Feb 10, 2020

Uh oh!

wangyum commented Feb 10, 2020

Uh oh!

SparkQA commented Feb 10, 2020

Uh oh!

peter-toth commented Feb 11, 2020

Uh oh!

wangyum commented Feb 12, 2020

Uh oh!

peter-toth commented Feb 12, 2020 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Uh oh!

wangyum commented Feb 12, 2020

Uh oh!

SparkQA commented Feb 12, 2020

Uh oh!

peter-toth commented Feb 13, 2020 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Uh oh!

wangyum commented Feb 13, 2020

Uh oh!

SparkQA commented Feb 14, 2020

Uh oh!

SparkQA commented Feb 16, 2020

Uh oh!

SparkQA commented Feb 17, 2020

Uh oh!

wangyum commented Feb 17, 2020

Uh oh!

SparkQA commented Feb 17, 2020

Uh oh!

HyukjinKwon commented Feb 25, 2020

Uh oh!

SparkQA commented Feb 25, 2020

Uh oh!

SparkQA commented Feb 26, 2020

Uh oh!

SparkQA commented Mar 7, 2020

Uh oh!

SparkQA commented Mar 20, 2020

Uh oh!

SparkQA commented Jun 8, 2020

Uh oh!

SparkQA commented Jun 12, 2020

Uh oh!

HyukjinKwon commented Jun 26, 2020

Uh oh!

tanelk left a comment

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

Choose a reason for hiding this comment

Uh oh!

tanelk Sep 7, 2020 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

wangyum commented Feb 10, 2020 •

edited

Loading

peter-toth commented Feb 12, 2020 •

edited

Loading

peter-toth commented Feb 13, 2020 •

edited

Loading

tanelk Sep 7, 2020 •

edited

Loading
