noVNC console integration #3967

davidjumani · 2020-03-16T06:53:57Z

Description

This feature provides novnc console for virtual machines.

It is developed based on noVNC 1.1.0
It includes changes in cloudstack :
(1) add a new websocket proxy to interact with the noVNC console
(2) a ConsoleProxyClient to read / write data from the vm vnc to the websocket.

Types of changes

Breaking change (fix or feature that would cause existing functionality to change)
New feature (non-breaking change which adds functionality)
Bug fix (non-breaking change which fixes an issue)
Enhancement (improves an existing feature and functionality)
Cleanup (Code refactoring and cleanup, that may add test cases)

Screenshots (if appropriate):

How Has This Been Tested?

(1) Works on kvm / ubuntu / centos
(2) Works on xs 75
(3) Works on VMware 6.5

blueorangutan · 2020-03-16T08:18:36Z

Packaging result: ✖centos6 ✔centos7 ✔debian. JID-1053

blueorangutan · 2020-03-16T10:09:34Z

Packaging result: ✖centos6 ✔centos7 ✔debian. JID-1054

blueorangutan · 2020-03-17T09:56:55Z

Packaging result: ✖centos6 ✔centos7 ✔debian. JID-1065

davidjumani · 2020-03-18T06:28:29Z

@ustcweizhou I've created this to use a java websocket proxy which supports client metrics reporting. Could you provide your comments

weizhouapache · 2020-03-18T08:36:01Z

@davidjumani cooooool.
I am currently busy on some other stuff. I will look at it when I am free.
@rhtyd has some ideas. maybe he can help you.

davidjumani · 2020-03-20T04:37:36Z

@rhtyd It's all good from my end, any comments ?

nvazquez · 2020-03-26T12:10:59Z

@blueorangutan package

blueorangutan · 2020-03-26T12:11:20Z

@nvazquez a Jenkins job has been kicked to build packages. I'll keep you posted as I make progress.

blueorangutan · 2020-03-26T12:37:23Z

Packaging result: ✔centos7 ✔debian. JID-1094

nvazquez

Thanks @davidjumani. I have tested manually and works nice. I have left some few comments and also wondering if we could include a jar instead of the noVNC codebase on the console proxy VM and serve it. Otherwise LGTM

nvazquez · 2020-03-26T20:16:42Z

server/src/main/java/com/cloud/servlet/ConsoleProxyServlet.java

+        if (param.getHypervHost() != null || !ConsoleProxyManager.NoVncConsoleDefault.value()) {
+            sb.append("/ajax?token=" + encryptor.encryptObject(ConsoleProxyClientParam.class, param));
+        } else {
+            sb.append("/resource/noVNC/vnc_lite.html?port=" + ConsoleProxyManager.DEFAULT_NOVNC_PORT + "&token="


Why not using vnc.html which provides more functionalities? Briefly tested invoking it and got this extra functionalities:

Wanted a simpler, minimalist UI, can add this when we get multi lingual keyboard working

nvazquez · 2020-03-26T20:20:36Z

server/src/main/java/com/cloud/consoleproxy/ConsoleProxyManager.java

    public static final String CERTIFICATE_NAME = "CPVMCertificate";

+    public static final ConfigKey<Boolean> NoVncConsoleDefault = new ConfigKey<Boolean>("Advanced", Boolean.class, "novnc.console.default", "true",
+        "If true, noVNC console will be default console for virtual machines", true);


I think it should be disabled by default at least until all hypervisors tested working properly

I've tested it on KVM, VMware and Xen and it works fine!

borisstoyanov · 2020-03-30T08:08:24Z

@blueorangutan package

blueorangutan · 2020-03-30T08:09:36Z

@borisstoyanov a Jenkins job has been kicked to build packages. I'll keep you posted as I make progress.

blueorangutan · 2020-03-30T08:42:25Z

Packaging result: ✔centos7 ✔debian. JID-1104

vladimirpetrov · 2020-04-02T12:11:53Z

@blueorangutan test

borisstoyanov · 2020-04-02T12:24:51Z

@blueorangutan test

blueorangutan · 2020-04-02T12:26:05Z

@borisstoyanov a Trillian-Jenkins test job (centos7 mgmt + kvm-centos7) has been kicked to run smoke tests

vladimirpetrov · 2020-04-03T08:35:22Z

@blueorangutan help

blueorangutan · 2020-04-03T08:36:08Z

@vladimirpetrov I understand these words: "help", "hello", "thanks", "package", "test"
Test command usage: test [mgmt os] [hypervisor] [additional tests]
Mgmt OS options: ['centos6', 'centos7', 'ubuntu']
Hypervisor options: ['kvm-centos6', 'kvm-centos7', 'kvm-ubuntu', 'xenserver-71', 'xenserver-65sp1', 'xenserver-62sp1', 'vmware-67u3', 'vmware-65u2', 'vmware-60u2', 'vmware-55u3', 'vmware-51u1', 'vmware-50u1']
Additional tests: list of space separated tests with paths relative to the test/integration directory, for example: component/test_acl_listvm.py component/test_volumes.py
Note: when additional tests are passed, you need to specify mgmt server os and hypervisor or use the matrix command.

Blessed contributors for kicking Trillian test jobs: ['rhtyd', 'nvazquez', 'PaulAngus', 'borisstoyanov', 'DaanHoogland', 'shwstppr', 'andrijapanicsb', 'Spaceman1984', 'Pearl1594', 'davidjumani', 'harikrishna-patnala', 'vladimirpetrov']

vladimirpetrov · 2020-04-06T12:15:15Z

@blueorangutan package

davidjumani · 2020-04-14T11:10:49Z

Verified with multi keyboard layouts! Have to configure the appropriate keyboard layout in the guest VM

vladimirpetrov · 2020-04-14T12:07:43Z

@blueorangutan package

blueorangutan · 2020-04-14T12:09:00Z

@vladimirpetrov a Jenkins job has been kicked to build packages. I'll keep you posted as I make progress.

vladimirpetrov · 2020-04-15T10:25:42Z

@blueorangutan package

blueorangutan · 2020-04-15T10:26:59Z

@vladimirpetrov a Jenkins job has been kicked to build packages. I'll keep you posted as I make progress.

blueorangutan · 2020-04-15T10:52:39Z

Packaging result: ✔centos7 ✔debian. JID-1168

andrijapanicsb · 2020-05-14T21:52:12Z

@blueorangutan test

blueorangutan · 2020-05-14T21:53:05Z

@andrijapanicsb a Trillian-Jenkins test job (centos7 mgmt + kvm-centos7) has been kicked to run smoke tests

blueorangutan · 2020-05-15T08:44:34Z

Trillian test result (tid-1531)
Environment: kvm-centos7 (x2), Advanced Networking with Mgmt server 7
Total time taken: 37093 seconds
Marvin logs: https://github.com/blueorangutan/acs-prs/releases/download/trillian/pr3967-t1531-kvm-centos7.zip
Intermittent failure detected: /marvin/tests/smoke/test_hostha_kvm.py
Smoke tests completed. 83 look OK, 0 have error(s)
Only failed tests results shown below:

Test	Result	Time (s)	Test File

blueorangutan · 2020-05-16T09:59:52Z

Packaging result: ✔centos7 ✔debian. JID-1229

blueorangutan · 2020-05-16T21:07:53Z

Packaging result: ✔centos7 ✔debian. JID-1230

andrijapanicsb

LGTM

tested manually as well.

andrijapanicsb · 2020-05-19T12:13:54Z

Travis log length exceeded - otherwise LGMT

Merging based on 2 x LGTMs, manual testing by 2 persons (Vladimir and me) and the regression test results passing 100%.

DaanHoogland · 2020-05-20T14:07:52Z

@davidjumani please have a look at https://builds.apache.org/job/cloudstack-pr-analysis/10377/artifact/target/rat.txt or equivalent of any new PR. it seems we missed some licensing checks on this PR.

* Adding noVNC repo * Adding support for noVNC * Adding Ctl+Esc * Removing device name from novnc header
